Key Features

Specification

Specification Category	Component / Metric	Details
Basic Info	Passenger Capacity	6 seats
	Color Options	White, Grey, Navy, Red, Khaki, etc.
Performance	Max. Speed	24 km/h
	Range (loaded)	80 km
	Climbing Ability (loaded)	20%
	Braking Distance	≤ 4.5m
	Min. Turning Radius	6.5m
	Min. Clearance	105mm
	Recharge Time	8–10h
	Payload	500 kg
Dimensions & Weight	Dimensions (LWH)	4050 * 1220 * 1950 mm
	F/R Tread	870 / 980 mm
	Axle Distance	2450 mm
	Curb Weight	710 kg
	Max. Loading (with payload)	1010 kg
Standard Configuration	Motor	48V / 5KW AC motor
	Controller	48V AC controller
	Battery	8V * 6pcs maintenance-free battery
	Body & Roof	ABS Plastic / PP material
	Windshield	One-piece see-through Polycarbonate
	Seats	Sponge + artificial leather
	Rearview Mirror	2 pcs
	Bumper	Front and rear Bumper
	Tire	Golf course use 18x8.50-8 6PR
	Chassis	Welded tubular steel with rust-proof coating
	Steering	Single reduction rack and pinion
	Front Suspension	Non-independent suspension, leaf spring
	Rear Suspension	Non-independent suspension, leaf spring
	Lighting System	2 headlights, turn signals
	Sound System	Horn, back-up buzzer
	Brake System	Dual rear wheel mechanical self-adjustable
	Charger	Automatic high-efficiency pulse, Overcharge Protection
	Dashboard	4 cup holders + 1 phone holder, turn signal switch, etc.
